Small busbar models for computer rooms include modular AC/DC busbars, insulated rack bonding bars, and compact power distribution busbars from manufacturers like Rittal, Chatsworth, TE Connectivity, and EAE Electric.1. Rittal RiLine Busbar Systems
  • Current Rating: Up to 2100 A
  • Poles: 3-pole and 4-pole options
  • Bar Spacing: 40 mm and 60 mm center distances
  • Features: Tool-free mounting, short-circuit resistant up to 65 kA, all-round contact hazard protection, compatible with NH slimline fuse-switch disconnectors and adaptors
  • Applications: Individual switchgear, controlgear, and modular distribution in computer rooms or industrial panels
2. Chatsworth (CPI) Busbars
  • Types: Primary Bonding Busbar (PBB) and Secondary Bonding Busbar (SBB)
  • Materials: Hard-drawn electrolytic tough pitch 110 alloy copper
  • Dimensions:
    • 10" (254 mm) for 1/4" single bolt lugs
    • 12" (305 mm) for 9 lugs
    • 20" (508 mm) for 17 lugs
  • Rack Bonding Busbars: 3/16” thick x 3/4” H, with #6-32 tapped lug holes on 1” centers
  • Vertical Rack Busbars: 36” and 72” lengths with self-clinching studs for equipment bonding
  • Applications: Rack grounding, consolidating equipment bonding, and controlling current paths in telecom or server rooms
3. TE Connectivity Busbars & Terminals
  • Portfolio: Standard and custom busbar solutions
  • Features: Cost-effective, reliable, and suitable for compact installations
  • Applications: Power distribution in computer rooms, switchboards, and modular panels
  • Selection: Users can filter by current rating, material, and mounting type to find small busbar models suitable for high-density racks
4. EAE Electric Power Busbars
  • Current Range: 32 A to 6300 A
  • Construction: Insulated aluminum or copper conductors in a closed modular body
  • Advantages: Modular, reusable, mechanically strong, lower energy loss, and effective heat dissipation
  • Applications: Distribution from transformers or panels to loads within computer rooms or data centers
  • Compact Options: Smaller current ratings (32–125 A) are suitable for small busbar installations in server racks or telecom rooms
5. Key Considerations for Small Busbars in Computer Rooms
  • Material: Copper for high conductivity; aluminum for lightweight and cost-effective solutions
  • Current Rating: Ensure the busbar can handle the expected load without overheating
  • Mounting: Tool-free or insulated mounting for safety and ease of installation
  • Spacing: Center-to-center spacing affects compatibility with rack-mounted equipment
  • Accessories: Include adaptors, fuse-switch disconnectors, and grounding kits for safe operation These models provide a comprehensive selection of small busbars suitable for computer rooms, offering modularity, safety, and efficient power distribution for high-density IT environments.
